It is "self supporting" (NO guys). Rated to hold 21sq.ft. of antennas to 85MPH. But needless to say if heavy winds are on the way it can be easily lowered.

It is a standard Heights Tower, tilt motor. The motor has an 80 to 1 Turn Ratio, it takes 11 minutes to go from horizontal to vert. The drive screw is 1.5" x 5' hardened steel.  The three bolts in the concrete, for the legs, are the same.

The Base: 9.5' Deep x 48" Diameter (5.9 yrds of Concrete)

The Tower is 62' high, with 14' of mast out the top.

Weight: 963 lbs.

The antennas:

2el, 40M Cushcraft @ 63'

3el, 6-20M SteppIR @ 73'

GP9 Comet Dual Band (2m/440) Vert.on top.
